Megalux LED

back to overview

high-performance L.E.D. light curing unit

The Megalux LED unit is an innovative light polyme- risation unit that was designed with implementation of the most recent findings in L.E.D.- technology. By using high-performance LED`s as light source emit- ting in the blue light spectrum, the light polymerisati- on is rendered possible for almost all popular light curing dental materials, e.g. composite filling materials, adhesives, fissure sealants and light curing cements.

The light intensity of 1,200 mW/cm2 with standard focus optical fibre 8 mm (1,600 mW/cm2 with focus optical fibre 6 mm), the integrated soft start as well as the adjustable exposure times of 10 s and 20 s provide universal applicability of the unit in all fields of light curing filling therapy.

Owing to the built-in lithium-ion battery, cordless work is possible. The integrated high-performance fan- less cooling block permits silent operation and working without overload for several using minutes. The light intensity of the LED lamp can be checked by an interprated radiometer in the charging pod.

technical datas:

main supply: 100-240 V/ 50-60 Hz

light intensity: 1.200 mW/cm2 with standard focus-optical fibre 8 mm

working cycle with full battery: 1.600 mW/cm2 with standard focus-optical fibre 6 mm

optical fibres: 300 x 10 s focus-optical fibre 8 mm (standard) focus-optical fibre 6 mm (optional)

weight of hand piece: 170 g
